The Reduced Tee PN16 is a three-way compression pipe fitting that connects two pipes of the same diameter on the through-run while branching off a smaller diameter pipe at the outlet. Rated at PN16 pressure, it is designed for pipelines where a smaller service line needs to be tapped off from a larger mainline without interrupting the main flow.

This makes the Reduced Tee PN16 different from an Equal Tee, where all three connections are the same size. The reduced branch outlet allows direct size reduction at the tee junction, eliminating the need for a separate reducer fitting on the branch line.

SSK Trading WLL is a trusted Reduced Tee PN16 supplier in Qatar, supplying contractors, MEP companies, plumbers, and irrigation engineers with fast delivery and competitive bulk pricing across Doha and all Qatar locations.

Key Features

  • 3-way fitting with equal through-run ends and one reduced branch outlet
  • PN16 pressure rating — handles up to 16 bar for reliable branching performance
  • All three ends are compression type — quick, tool-free installation
  • Leak-proof EPDM O-ring seals with stainless steel grip rings on all ends
  • Eliminates need for a separate reducer on the branch line
  • UV and corrosion resistant — built for Qatar's outdoor and high-temperature conditions
  • Available in multiple size combinations for mainline and branch requirements

Technical Specifications

Specification Details
Type Reduced Tee (unequal 3-way fitting)
Pressure Rating PN16 (16 bar)
Through-Run Ends 2 × equal diameter PE / HDPE connections
Branch Outlet 1 × smaller diameter PE / HDPE connection
Material HDPE / PP
Seal EPDM O-ring all ends
Grip Ring Stainless steel all ends
Application Water supply, plumbing, irrigation, MEP



Common Uses

  • Tapping a smaller service line from a larger water supply mainline
  • Branching smaller irrigation laterals from a main distribution pipe
  • Creating service connection points on infrastructure water pipelines
  • MEP systems requiring a reduced branch outlet at a pipeline junction
  • Construction sites needing mainline flow with reduced-size branch supply

Bulk Supply in Qatar

SSK Trading supplies Reduced Tee PN16 fittings in bulk for contractors, MEP companies, and industrial buyers across Qatar. Most orders are delivered within 1–2 working days, with same-day delivery available for urgent site requirements. No minimum order quantity  we support both small purchases and large project-based supply.

Product features

3-way PN16 compression fitting with two equal through-run ends and one
reduced branch outlet for smaller pipe connections. Rated at 16 bar with
EPDM O-ring seals and stainless steel grip rings on all three ends.
Eliminates the need for a separate branch reducer. UV and corrosion
resistant for Qatar's outdoor conditions.

Materials and care

Body: HDPE / PP | Seal: EPDM O-ring (all 3 ends) | Grip Ring: Stainless steel
Pressure Rating: PN16 (16 bar)
Confirm mainline OD and branch OD before ordering — e.g. 50mm x 32mm.
Cut all pipe ends cleanly before insertion. Hand-tighten only.

Merchandising tips

Always confirm both the mainline pipe OD and the branch pipe OD before
ordering — e.g. 50mm through-run x 32mm branch — to ensure the correct
size combination for your pipeline layout.

Install the reduced branch outlet facing the direction of your service
line — the two equal ends should align with your mainline flow direction
for best hydraulic performance.
